Shure MXWAPT8

Overview

The MXWAPT is a 8-channel wireless access point compatible with Microflex Wireless microphone systems. It uses automated frequency coordination to assign clean frequencies to wireless microphones and manages two-way wireless transmission of encrypted audio and control signals. Power to the unit (via PoE) and Dante digital networked audio are both supplied over a single Ethernet cable to simplify installation, and the supplied mounting plate and paintable cover allow discreet placement in boardrooms and conference rooms where low visibility is preferred.

• Easy installation:

Includes wall / ceiling mounting plate and connects to the system over single Ethernet cable (PoE compatible)

• Plenum rated:

Meets rigorous fire safety test standards for installation above drop ceiling tiles

• Scalable configurations:

Multiple units can be combined support configurations of up to 40 compatible channels (80 in Europe and select countries).

• Bi-directional wireless:

Provides return channel audio to wireless transmitters and enables real-time remote control of all wireless microphone settings

• Automated frequency coordination:

Automatically scans available spectrum, coordinates clean frequency assignments, and moves channels away from unexpected interference

• Dante digital networked audio:

Transports low-latency digital audio received from wireless microphones over Cat5e cable to any other Dante-equipped device

• Encrypted wireless:

AES 256-bit encryption for secure transmission

• Selectable output power:

Optimize spectrum usage by selecting the appropriate wireless output power for the desired operating range

• Diagnostic LEDs:

LEDs offer easy visual reference to system activity and indicate power, wireless connection, and network audio status
